Product Description

3.3V 5V 12V 24V 2 Channel Relay Module High and low Level Trigger Dual Optocoupler Isolation Relay Module

Product Description:

The module adopts genuine quality relay, the maximum load of the normally open interface: AC 250V/10A, DC 30V/10A;
Using double optocoupler isolation, strong drive capability, stable performance; trigger current 5mA;
Module operating voltage is 5V;
Each channel of the module can be triggered by jumper high or low level;
Fault-tolerant design, even if the control line is broken, the relay will not move;
Power indicator (green), 2 relay status indicators (red)
User-friendly interface design, all interfaces can be directly connected through the wiring terminals, very convenient

Module interface:

DC+: Connect to the positive pole of the power supply (voltage is relay 5V)
DC-: Connect to the negative pole of the power supply
IN1-IN2: According to the setting of each channel, the corresponding relay can be controlled by high or low level.

Relay output:

NO1-NO2: Normal open interface of the relay. Before the relay is closed, it is left unconnected. After picking up, it is shorted to COM.
COM1-COM2: Relay Common Interface
NC1-NC2: Normally closed relay interface. Before the relay is closed, it is short-circuited with COM.

High and low level trigger selection:

S1-S2 is the high and low level trigger selection for Relay 1 - 2;
When com is shorted to low, the corresponding relay is a low level trigger. When com is shorted to high, it is a high level trigger.
